Home>Products> Other Parts > Bearing Swing

Slewing Ring PC200

1. Park the excavator on a level ground and lower the front-end working device to the ground.
2. Before measuring, it is necessary to ensure that there are no people or obstacles around the excavator to ensure safety.
3. Fix the dial gauge holder on the lower frame so that the measuring point of the dial gauge is 20 millimeters away from the rotating seat ring.

Send Inquiry

Description

Slewing Ring PC200 PC220-8 swing circle for komatsu 206-25-00200

product-800-533

Detecting Slewing Ring PC200

1. Park the excavator on a level ground and lower the front-end working device to the ground.

2. Before measuring, it is necessary to ensure that there are no people or obstacles around the excavator to ensure safety.

3. Fix the dial gauge holder on the lower frame so that the measuring point of the dial gauge is 20 millimeters away from the rotating seat ring.

4. Fully extend the stick and retract the bucket, setting the dial gauge to the zero position.

5. Lower the bucket to the ground and support the track to a distance of 15-30 centimeters, observe the dial gauge reading and record it three times.

Note: The measurement value may vary depending on the fixed position of the magnetic base of the dial gauge, so it is necessary to measure multiple times.

It is normal for the clearance between the slewing bearing to be between 0.5 and 3mm. If it exceeds 3mm, it is necessary to consider repairing or replacing the slewing bearing.

There are two reasons for the failure of the slewing bearing.The first is normal wear and tear, and the second is improper maintenance. For example, if you do not frequently add lubricating oil to the slewing ring, or if you add too much butter to the slewing ring and squeeze out the sealing ring, and do not replace it with a new seal in the later stage, it will accelerate wear and lead to larger faults. So when you receive our PC200-8 sleeping ring 206-25-00200 from our company, you don't need to add lubricating oil anymore, and even add a small amount multiple times later

Slewing Ring PC200:Standard size of hole diameter for installing joints

Can be painted according to customer requirements

208-26-00211	714-07-43323	421-22-12870	707-88-26660
708-88-51140	6738-81-8041	6222-61-1200	6240-61-3800
723-40-51102	6151-11-5160	6162-15-5190	705-56-34040
708-1V-00212	708-3T-13420	708-3D-04420	421-01-H2150
702-21-02940	6732-81-3110	6754-61-1010	154-30-01010
DK154200-7020	600-185-4210	154-30-01010	427-N42-1121
427-N42-1151	427-N42-1161	427-N42-1133	6240-61-3800
